Cormach marine cranes

Whatever Cormach marine crane you are looking for, we can locate it, new or used, and deliver it to your ship, barge or dock anywhere in the world.

All types of Cormach marine cranes: barge cranes, ship cranes, platform cranes and boat cranes. Tell us the crane and the job, and we will find a Cormach that can do it. Custom Cormach configurations are available for most applications.

Why Cormach cranes look different

A Cormach uses a twin column turret on a large slew bearing, driven by an external motor and gearbox, on every model in the range. Most makers keep that layout for their biggest cranes and use a single column with rack and pinion rotation below that.

• Stress is spread, not concentrated. The twin columns carry lifting and shock loads down into the slew bearing and the base, instead of into one point at the top of a single column.
• Symmetrical about the centerline, with no offset columns or booms, so pins, bearings and bushes wear evenly.
• A low center of gravity, with the heavy parts down near the mounting.
• Continuous rotation on the larger models and as an option on the smaller ones.
• Two main boom cylinders, one on each side.

Cormach marine models

Cormach marine cranes are built in a long range of capacities. The marine models include:

• 8700 E4, 9800 E3, 12000 E4, 16600 E4 and E4F, 17900 S3
• 18000 E4F ASC, 22500 E4F64 ASC and E6 ASC, 25500 E8, 27500 E6F64 and E8 ASC Plus, 27700 S8 ASC Plus
• 28200 E8 ASC, 34000 E8 and E6F64 ASC Plus, 38000 E8 and E8F, 40400 E8 and E8F ASC Plus
• 49000 E6F134, E8 and E8F64, 51800 E8, E8F64 and E6F134 ASC Plus, 60200 E6 and E6F
• 65000 E6 and E6F ASC Plus, 88000 E6 ASC Plus with or without jib, 100000 E2 ASC Plus
• 125000 E9 and F9F186 ASC Plus, 180000 E6 ASC Plus and JIB4, 230000 E9 ASC Plus and JIBC4

Call with the capacity and reach you need and we will tell you which model fits and what is available now, new or used.

Cormach parts and service

Seal kits, cylinders, hoses, valves, slew bearing and drive parts and controls for Cormach cranes, plus service and repair at the Orlando shop.
